EnerSys DataSafe HX 12HX150

  • Nominal Voltage: 12
  • WPC (watts per cell) for 15 min. to 1.67 VPC at @ 77°F: 160
  • Short Circuit Current (A): 1,740
  • Max Discharge Current: 298
  • Internal Resistance (mΩ): 7
  • Dimensions (inches): 7.8 x 6.5 x 6.7
  • Weight: 32 lbs
  • Designed specifically for UPS applications
  • Manufactured in EnerSys ISO 9001:2000 registered production facilities
  • Part no: 12HX25, 12HX35, 6HX50, 12HX50, 12HX80, 12HX100, 12HX135B, 12HX135R, 12HX150, 12HX205, 12HX300, 12HX330, 12HX400, 12HX505, 12HX540, 6HX800
  • Download specsheet
  • Download MSDS
SKU: 12HX150 Category:
Description
Additional information

The DataSafe HX 12HX150, as part of the EnerSys DataSafe HX family, was created to provide backup power for high-rate applications and vital systems. The HX 12HX150 is air freight approved and meets UL safety standards. The low level of gas evolution makes the HX 12HX150 a prudent choice for low-ventilation areas.

The DataSafe HX 12HX150 is made up of high-performance, brass-threaded faston terminals; a receptacle and bolt terminal of the same materials; opposite charged lead-calcium-tin alloy plate grids; and individual flame-arresting cell vents. It has a decade-long optimal lifespan and, like all EnerSys batteries, sustains 100% battery capacity at initial discharge. A flame-retardant cover and case for this battery are available from EnerSys.
